Key Points
- A rhinoplasty graft is a piece of cartilage (occasionally bone or tissue) placed in the nose to support, shape or open it. Grafts are a routine part of modern rhinoplasty, not a sign that something has gone wrong.
- Many grafts are there to help you breathe. Spreader grafts open the internal nasal valve; rim and alar grafts stop the nostrils collapsing when you breathe in.
- Breathing improves substantially when grafts treat a real valve problem. A 2026 review of 1,210 patients found nasal obstruction scores fell by 40 to 55 points on a 100-point scale after valve surgery.
- Septal cartilage is the first choice, followed by ear and then rib cartilage when more is needed, usually in revision rhinoplasty.
- Rib cartilage is strong but has trade-offs. Pooled data show warping in about 3% of patients and a thickened chest scar in about 5%.
- Harvested cartilage does not grow back, but taking it from the septum or the bowl of the ear does not change how the ear looks or how the septum works.
Cartilage grafts are one of the main tools a nose surgeon has. They let the surgeon build support where the nose is weak, open a narrow airway, refine the tip, straighten a crooked middle third or restore height to a bridge that has been over-reduced. This guide explains each of the common grafts, what they are made from, the breathing problems they treat, and the risks worth knowing about. If your main question is where the cartilage comes from, see our companion guide to the cartilage graft nose job.
What Is a Rhinoplasty Graft?
A rhinoplasty graft is a piece of tissue, almost always cartilage, that is shaped and stitched into the nose. Grafts do three jobs:
- Support: reinforcing weak or collapsing cartilage so the nose holds its shape and the airway stays open.
- Shape: adding definition, projection or length, especially at the tip.
- Replace: rebuilding cartilage that is missing after injury or previous surgery.
Grafts also resist the tendency of cartilage to drift back towards its original shape, which is part of why the result lasts, as our guide to how long rhinoplasty results last explains.
Nasal Obstruction Symptoms: When Are Grafts Needed for Breathing?
A blocked nose is not always caused by the septum. The nasal valves, the narrowest parts of the airway, can collapse or be too narrow, and this is a common and under-recognised cause of nasal obstruction[1]. The internal nasal valve sits about a centimetre inside the nostril, where the side cartilage meets the septum. The external valve is the nostril itself. Weakness of the side wall at either point is called lateral wall insufficiency[2].
Symptoms that suggest a valve problem include:
- A nose that feels blocked on one or both sides, often worse when you breathe in hard or exercise.
- Nostrils that visibly pull inwards or stick shut on a deep breath.
- Breathing that improves when you pull your cheek gently outwards or use nasal strips.
- Mouth breathing, snoring, a dry mouth on waking or broken sleep.
- Blockage that began or worsened after a nose injury or previous rhinoplasty.
At consultation, your surgeon will examine the inside of your nose, check the valves while you breathe in, and often ask you to complete the NOSE (Nasal Obstruction Symptom Evaluation) questionnaire, a validated 0 to 100 score of how blocked your nose feels. A 2026 systematic review of 72 studies in Diagnostics ↗ found no single test is definitive, but that a combination of examination, symptom scores and selected airflow tests gives the clearest picture, and that surgery for a confirmed valve problem reduced NOSE scores by an average of 40 to 55 points across 1,210 patients[1].
Other causes of blockage, such as a deviated septum, enlarged turbinates, allergy or polyps, need different treatment, and many patients have more than one. See also our guide to nasal valve collapse.
What Are Spreader Grafts?
Spreader grafts are thin strips of cartilage, roughly matchstick-sized, placed along both sides of the septum where it meets the upper side cartilages. They widen the internal nasal valve by a millimetre or two, which makes a large difference to airflow, as resistance through a narrow tube rises sharply as it narrows.
Spreader grafts are used to:
- Open a narrow internal valve and improve breathing. In a randomised study of 48 patients, nasal airflow increased after surgery with both spreader grafts and the alternative autospreader technique[3].
- Prevent the middle of the nose collapsing after a hump is removed. Removing a dorsal hump opens the roof of the nose; without support, the side walls can fall inwards and narrow the valve.
- Straighten a crooked middle third. A single curved spreader graft on one side can push a C-shaped bend straight; in a series of 18 patients, both the visible deviation and the valve angle improved significantly[5]. See can you fix a crooked nose with rhinoplasty.
- Even out an hourglass-shaped bridge, where the nose looks pinched in the middle.
Do spreader grafts make the nose wider?
They can add a little width to the middle of the bridge, which is why they are sized and placed carefully. Many surgeons use autospreader flaps instead, folding the patient’s own upper side cartilage inwards rather than adding new cartilage. In a 2026 study of patients given prophylactic autospreader flaps, bridge width at one year was about 1 mm greater than before surgery, a difference that was not statistically significant, and breathing was preserved[4]. In practice, a correctly sized graft is rarely noticeable from the front.
What Are Tip Grafts?
Tip grafts are small, shaped pieces of cartilage, often shield- or cap-shaped, placed on or in front of the tip cartilages. They are used to:
- Increase projection, so the tip sits further from the face.
- Add definition to a broad or poorly defined tip.
- Lengthen a short nose when placed below the tip.
- Correct tip asymmetry.
A columellar strut, a strip of cartilage placed between the two tip cartilages, supports the tip from below and stops it drooping as healing tissue contracts. A septal extension graft fixed to the end of the septum gives stronger control over tip position and length. Tip work is central to a tip rhinoplasty.
In people with thin skin, tip grafts are bevelled and sometimes covered with soft tissue so their edges do not show through over time.
What Are Rim Grafts and Alar Batten Grafts?
Rim grafts (alar rim grafts) are slim strips of cartilage placed along the edge of the nostril. They support the nostril so it does not collapse on breathing in, and can lower a nostril rim that is pulled up or notched by a few millimetres, improving symmetry.
Alar batten grafts are slightly larger pieces placed in the side wall of the nose, over the area that collapses on inspiration. They are one of the main treatments for external valve collapse and lateral wall insufficiency[2]. They can add slight fullness to the side of the nose, which surgeons balance against the breathing benefit.
Placed correctly, neither graft should be seen or felt.
Other Grafts Used in Rhinoplasty
- Dorsal onlay grafts: cartilage, often diced and wrapped in fascia (the thin covering of muscle), placed along the bridge to raise a low or over-reduced dorsum. See augmentation rhinoplasty.
- Butterfly grafts: a curved piece of ear cartilage placed across the upper tip to open both valves at once, mostly used in revision cases.
- Radix grafts: small grafts at the top of the bridge, between the eyes, to deepen or raise the starting point of the nose.
- Camouflage grafts: crushed cartilage or soft tissue used to smooth small irregularities.
Where Does Cartilage for a Rhinoplasty Graft Come From?
Septal cartilage
The septum, the wall between the two nostrils, is the first choice. It is straight, strong, already inside the nose, and taking it adds no new scar. Enough is always left to keep the septum supporting the nose. In septorhinoplasty, the bent part of the septum is often the cartilage used for the grafts.
Ear cartilage
When the septum has been used or is too small, cartilage is taken from the concha, the bowl of the ear behind the ear canal, through an incision hidden behind or inside the ear. It is softer and naturally curved, which suits tip and rim grafts but not spreader grafts, which need to be straight.
Rib cartilage
Rib cartilage supplies the most material and is the strongest, so it is used for major reconstruction, significant dorsal augmentation and complex revision surgery. It is taken through a short incision under the breast or over the lower chest. A 2015 meta-analysis of 491 patients in JAMA Facial Plastic Surgery ↗ found low overall complication rates, but noted warping of the graft in about 3% and a thickened chest scar in about 5%; pneumothorax (air leaking around the lung) did not occur in the pooled studies[6]. Surgeons reduce warping by carving the cartilage symmetrically or dicing it.
Some surgeons also use donated, processed rib cartilage from a tissue bank, which avoids a chest incision. Your surgeon will discuss whether this is appropriate for you.
Risks of Rhinoplasty Grafts
Most grafts heal in without problems. Possible issues include:
- Visibility: a graft edge showing through thin skin, more likely over time as swelling settles.
- Shifting or warping, which may need correcting.
- Width: slight widening of the middle third with spreader grafts or of the side walls with batten grafts.
- Donor site: soreness and a scar at the ear or chest; rarely a change in ear shape.
- Infection, which is uncommon[6].
The general risks of nose surgery, swelling, bleeding, numbness and the possibility of revision, apply as with any rhinoplasty. Swelling takes up to a year to settle fully; see our rhinoplasty recovery guide.
Frequently Asked Questions About Rhinoplasty Grafts
What is a nose graft?
A nose graft is a piece of cartilage, or occasionally bone or tissue, placed in the nose during rhinoplasty to support, shape or open it. Common types are spreader grafts to open the airway, tip grafts to shape the tip, and rim grafts to stop the nostrils collapsing.
Does ear cartilage grow back after rhinoplasty?
No. Cartilage does not regenerate once it is removed. Taking it from the bowl of the ear leaves the ear’s outline and projection unchanged, so most people notice no difference in how the ear looks.
Do spreader grafts improve breathing?
Yes, when the internal nasal valve is narrow. Spreader grafts hold the valve open by a millimetre or two, and studies show airflow and symptom scores improve after surgery[1][3]. They will not fix blockage caused by other problems such as allergy or swollen turbinates.
Can a graft be seen or felt?
It should not be once healed. In thin-skinned noses, grafts are shaped with bevelled edges and sometimes covered with soft tissue to keep them invisible. A graft that becomes visible can usually be refined.
Is rib cartilage rhinoplasty safe?
Complications are uncommon. In pooled data, warping occurred in about 3% of patients and a thickened chest scar in about 5%, with no cases of air leaking around the lung[6]. Rib cartilage is usually reserved for revision or major reconstruction.
How long do rhinoplasty grafts last?
Your own cartilage becomes part of the nose and is permanent. Results can still change slowly as the skin and soft tissue age, which is true of any rhinoplasty.
References
- Daoud M, Gherasie LM, Fufezan ML, et al. Diagnostic approaches and surgical outcomes in nasal valve dysfunction: a systematic review. Diagnostics 2026;16(9):1324. doi:10.3390/diagnostics16091324 ↗
- Rossi Meyer MK, Most SP. Evaluation and management of lateral wall insufficiency. Otolaryngologic Clinics of North America 2024;58(2):269–278. doi:10.1016/j.otc.2024.07.027 ↗
- Aydoğdu I, Bayram AA, Aydoğdu Z. Assessment of functional outcomes of an autospreader flap and spreader graft in rhinoplasty. Journal of Craniofacial Surgery 2022;33(3):e257–e260. doi:10.1097/SCS.0000000000008044 ↗
- Jabbour N, Pelligrini W, Shehan J, Ezzat W. Dorsal width and functional outcomes with use of autospreader flaps in cosmetic rhinoplasty. Aesthetic Surgery Journal 2026. doi:10.1093/asj/sjag145 ↗
- Elsayed AI, Elbahrawy A, Sorour S, Elsadek A, Fouad YA. The use of a unilateral curved spreader graft in the management of crooked nose deformity. Annals of Plastic Surgery 2024;92(2):156–160. doi:10.1097/SAP.0000000000003724 ↗
- Wee JH, Park MH, Oh S, Jin HR. Complications associated with autologous rib cartilage use in rhinoplasty: a meta-analysis. JAMA Facial Plastic Surgery 2015;17(1):49–55. doi:10.1001/jamafacial.2014.914 ↗
Rhinoplasty at Centre for Surgery
Our surgeons perform over 100 rhinoplasties a year at our private hospital at 95–97 Baker Street, Marylebone, including functional, primary, ethnic and revision surgery. The consultant who assesses you is the consultant who performs your operation, and every surgeon is registered with the General Medical Council.
At consultation your surgeon will examine both the outside and the inside of your nose, assess your breathing, and explain which grafts, if any, you need and where the cartilage would come from. After surgery, patients spend three to four hours in our recovery unit, monitored by specialist recovery nurses. We recommend a two-week cooling-off period before any surgery. Prices are on our rhinoplasty cost guide, and finance is available, subject to status; see our finance options.
To arrange a consultation, contact us or call 020 7993 4849.
